Winnebago View Product Information
Winnebago View and Navion Specifications
The Winnebago View and Navion are built on the innovative and fuel-efficient Mercedes-Benz Sprinter chassis and are styled with upscale details throughout. Winnebago is known for their industry-leading innovations, and the Winnebago View and Navion offer an unparalleled Class C experience. Contemporary design, premium furnishings, carefully engineered systems and functional storage are combined to create a motorhome that’s as easy to live in as it is to drive.
Continue reading to learn about the specifications and features of the Winnebago View and Navion.
Floorplans
The Winnebago View and Navion are available in three floorplans, the 24D, 24J and 24V. Both the 24D and 24J feature a plush U-shaped dinette with foot rests with the full bath situated in the rear of the RV while the 24V includes the luxurious TrueComfort+ sofa and the bathroom is mid-coach. All three floorplans include the convenient cabover bunk that measure 49″ x 75″. One of the key differences between these floorplans is the location and style of the bed. The 24D, arguably the most popular of the floorplans, has a sofa seating area that easily converts to a Murphy+ bed with European suspension. Comparatively, the 24J features a rear corner bed and the 24V has two rear twins beds that convert into one large sleeping space with the flex bed system.
Winnebago View & Navion Weights & Measurements
- Exterior Length – 25′ 6″
- Exterior Height – 11′
- Exterior Width – 7′ 6.25″
- Awning Length – 16′
- Interior Height – 6′ 8″
- Interior Width – 7′ 3″
- Freshwater Tank Capacity (gal.) – 30 (24D) / 37 (24J) / 31 (24V)
- Water Heater Capacity (gal.) – Continuous
- Holding Tank Capacity – Black (gal.) – 41
- Holding Tank Capacity – Gray (gal.) – 41
- LP Capacity (lbs.) – 50.76
- Fuel Capacity (gal.) – 24.5
- GCWR (lbs.) – 15,250
- GVWR (lbs.) – 11,030
- GAWR – Front (lbs.) – 4,410
- GAWR – Rear (lbs.) – 7,720
- Wheelbase – 170″
- Sleeps – 4
Winnebago View & Navion Chassis
- Mercedes-Benz® Sprinter Chassis
- 3.0 L 6-cylinder, 188-hp, turbo-diesel engine 7G -Tronic automatic transmission, 220-amp. alternator
- Adaptive ESP technology
- Hydraulic brakes w/ABS
- Trailer Hitch6 5,000-lb. drawbar/500-lb. maximum vertical tongue weight w/7-pin connector
- Stylized aluminum wheels
- Spare tire
Optional Equipment:
- Hydraulic leveling jacks w/automatic controls (front and rear)
Winnebago View & Navion Cab Conveniences
- MBUX® Touchscreen Multimedia Infotainment Center with Navigation, WiFi hotspot, Intelligent Voice Control and Rear Color Camera
- Airbags driver, passenger, side and curtain
- Heated power control cab seats — armrest, adjustable lumbar support, headrest, recline, slide, and manual swivel
- 3-point seat belts
- Climate control
- Leather-wrapped steering wheel
- Power door locks w/remote
- Power windows
- Power mirrors w/defrost and turn signals
- Cruise control
- Active lane keeping assist
- Active braking assist
- Rain sensor w/integrated wet wiper system
- Power assist steering w/tilt wheel
- 12V/USB powerpoints
- Folding windshield and cab window blinds
- Dash appliqué package
- 2 cab seat lounge cushions
- Hill start assist
- Crosswind assist
- Attention assist
Optional Equipment:
- Cab seats w/Ultrafabrics® UF Select covering
Winnebago View & Navion Interior
- 32″ HDTV
- U-Shaped dinette (24D, 24J)
- TrueComfort+ sofa w/table (24V)
- LED lights
- Satellite system ready
- Amplified digital HDTV antenna
- Powered roof vent — rain cover, electric lift, remote control, thermostat operation (front bunk)
- MCD solar/blackout roller shades
- Systems monitor panel
- Tinted coach windows
- Assist bar
- Vinyl flooring throughout
- Soft vinyl ceiling
- 110V/12V/USB charging stations
- Roof wiring access port
- Toe kick lighting
Optional Equipment:
- Dual pane acrylic windows
- Dual recliners w/table (24V)
- Theater seating w/swivel tables (24D, 24J)
- Entertainment System Blu-ray disc player and Bluetooth® Soundbar
Winnebago View & Navion Galley
- Laminate countertops
- Microwave/convection oven w/touch control
- 2-burner induction & LP range cooktop
- 10.0 cu. ft. (12V) 2-door compressor-driven refrigerator/freezer
- Cold water filtration system
- Water-pump switch w/light
- Pantry (24D, 24J)
- Cabinets with accent lighting
- Lighted soft close drawers
- Integrated paper towel holder
- Double stainless steel sink w/two sink covers
- Mini blinds
- Toe kick lighting
Winnebago View & Navion Bath
- Shower 24″ x 32″ (24D, 24J)
- Shower 19″ x 28″ x 34″ (24V)
- Retractable, self-cleaning shower screen
- Oxygenics® flexible showerhead
- Shower skylight
- Porcelain toilet w/foot pedal and sprayer (24J, 24V)
- Composite Toilet (24D)
- Powered roof vent w/rain cover
- Lavatory cabinet
- Medicine cabinet
- Mini blinds (24D)
- Towel rack (24V)
- Towel bar(s) (24J, 24V)
- Tissue holder
- Removable clothes rod
- Robe hook(s)
- Integrated facial tissue holder
- Toe kick lighting
Winnebago View & Navion Bedroom
- Murphy+ bed w/deluxe queen mattress, Euro-suspension system, gel foam topper (24D)
- Corner bed w/headboard, foam mattress, mattress cover and access to storage below (24J)
- Flex Bed System twin beds/king bed w/foam mattresses and access to storage below (24V)
- FROLI® deluxe sleeping system (24J, 24V)
- MCD blackout roller shades
- Wardrobe cabinet
- Metal clothes rod
- Room divider curtain
- Anything Keeper drop down storage above bed (24J, 24V)
- 110V/12V/USB charging stations (24J, 24V)
- 110V/USB charging station (24D)
- 24″ LED HDTV (24J, 24V)
Winnebago View & Navion Exterior
- Automatic entrance door step
- LED porch light w/interior switch
- Stepwell light w/interior switch
- Front and rear mud flaps
- Aluminum cab steps w/logoed tread and loop attachment
- Powered patio awning w/LED lights and Bluetooth® control
- Large pass-through storage compartment (24D, 24J)
- Ladder
Winnebago View & Navion Heating & Cooling System
- 15,000 BTU air conditioner w/heat pump
- 20,000 BTU low-profile ducted furnace
Winnebago View & Navion Electrical System
- Service Center light, cable TV input, 30-amp. power cord, portable satellite dish hookup, QuickPort® service connection hatch
- Automatic dual battery charge control
- Exterior AC duplex
- Exterior antenna jack
- Generator auto transfer switch
- Battery disconnect system (coach)
- AC/DC load center/converter unit
- 2 deep-cycle, Group 31 RV batteries
- 3,600-watt Cummins Onan® MicroQuiet™ LP generator
- 2,000-watt pure sine wave DC/AC inverter
- (2) 100-watt solar panel/battery charger w/controller, junction box, and plug for additional portable solar panel
Optional Equipment:
- Lithium Ion Smart Batteries
- 3,200-watt Cummins Onan® Diesel generator
Winnebago View & Navion Plumbing System
- Service Center — color-coded labels, pressurized city water hookup/tank diverter valve, drainage valves, exterior wash station w/lighted pump switch
- Truma AquaGo® Comfort Plus Tankless water heater
- TrueLevel™ holding tank monitoring system
- Heated drainage system
- 10′ sewer hose
- Winterization Package water heater bypass valve and siphon tube
- On-demand water pump
- Lockable water tank fill
- Sewage pump macerator (24V)
- Permanent-mount LP tank w/gauge
- LPG accessory connection (patio area)
- Black holding tank flushing system
Winnebago View & Navion Safety
- LPG leak, smoke and carbon monoxide detectors
- Fire extinguisher
- Ground fault interrupter
- Child seat tether anchor (24D, 24J)
Winnebago View & Navion Warranty
- 12-month/15,000-mile limited warranty*
- 36-month/36,000-mile limited warranty on structure*
- 10-year limited parts-and-labor warranty on roof skin*
*Ask Lichtsinn RV for complete warranty information.
With upscale details throughout, the Winnebago View and Navion offer the freedom to live large in a compact coach. The View and Navion’s industry-leading amenities promise an incredible Class C experience, and with the dependable diesel-powered Sprinter chassis, you can stay in control, even off-grid.
